Jiangsu Hongda Powder Equipment Co., Ltd. (formerly: Jiangyin Hongda Machinery Manufacturing Co., Ltd.) was established in 1992. It is a comprehensive enterprise integrating R&D, production and trade. The company is a member of the China Pharmaceutical Equipment Industry Association. The company has import and export rights and has an independent production base with an area of 13,800 square meters and a construction area of 9,160 square meters. The company's main products include crushers, screeners, mixers, granulators, dryers and conveyors.
Professional Departments
We have a finishing workshop, raw material plate cutting and processing center, welding workshop, polishing workshop, assembly center, and a dedicated product design and development department and product quality inspection department. Ensure that every link of the product from research and development to finished products is strictly controlled.
Professional Team
We have a technical team of more than 300 professionals with rich industry experience and excellent professional capabilities.
Patent Certificate
We have obtained ISO9001:2008 international quality management system certification and EU CE certification, and hold 9 national intellectual property patents.
Quality Service
We provide a full range of technical support and after-sales service. We have an experienced after-sales service team that can respond quickly after receiving customer feedback and provide timely and effective solutions.
The crushing and grading operations are efficiently completed through wind separation, thanks to the combination of the high-speed rotating rotor and the fixed guide. As a result, energy consumption is significantly reduced while maintaining high efficiency.
Another advantage of using a jet mill for crushing materials is the consistent and uniform feeding and discharging. This results in a more even and controllable crushing fineness. In addition, the material uniformity is greatly improved during the crushing process. Thanks to these benefits, the jet mill is a preferred option for many industries that require precise and consistent particle size distributions in their products.
This crushing machine exhibits remarkable adaptability to different types of materials, making it the ideal choice for crushing hard, brittle, easily damaged, temperature-sensitive, or water-rich materials.
The structure of this system is quite simple, consisting solely of a main engine, a centrifugal fan, and a pipeline. Due to its uncomplicated nature, it is easy to install and maintain.
Working Principle
The purpose of the airflow crusher machine is to pressurize gases. Powder materials (about 60 mesh) are fed through the sprayer and fed evenly and continuously into the mill. As the gas flows from high-speed air, it enters the pulverizing room through the pulverizing nozzles situated on the periphery of the chamber. This impact and rubbing of powder particles leads to their pulverization, and the collected ultra-fine particles are separated by the cyclone separator. Further fine particles get collected into the filter collector, and gases are discharged through it. The machine has a simple structure, is small in volume, and can be easily cleaned.
Product Parameters
|
/ Parameters/Model |
BQF-50 |
BQF-100 |
BQF-200 |
BQF-300 |
BQF-400 |
BQF-600 |
|
Mpa Milling Pressure |
0.65-0.95 |
|
||||
|
m3/min Air consumption |
1 - 1.25 |
1.75 - 2.2 |
3.3-3.5 |
6-7.5 |
10 - 13 |
25 - 32 |
|
KW Air compressor power |
11 |
15 |
37 |
55 |
75 |
132 |
|
Kg/h Handle capacity |
0.2 - 1 |
0.5 - 5 |
5-30 |
10-50 |
50 - 150 |
300-600 |
|
Kg Weight |
60 |
140 |
55 |
80 |
180 |
330 |
|
mm Dimensions |
890×750×868 |
1050×500×1380 |
1700×650×1580 |
510*510*630 |
890×750×868 |
1000X1000X900 |
Our Customization Process
Enquiry: Clients can provide us with your design and materials to OEM.
Design: Our experienced design team will create material processing drawings for your approval.
Sample: Contact us to request the sample you are interested in or customize the sample you want.
Quote: Based on the customized information or order quantity you provide, we will provide you with a cost-effective quotation.
Confirm: We will confirm the production of bulk goods with the samples and processing drawings confirmed by both parties and the negotiated delivery standards.
Production: Once we receive the deposit, drawings and samples confirmed by both parties, production will begin.
Quality checking: We conduct thorough quality checks before shipping to ensure the highest standards are maintained.
Packing and Shipping: Our team will meticulously pack the goods and arrange for safe shipping.
After-sale service: We are committed to providing excellent after-sales service, supporting you from the moment you receive the goods until the completion of installation of your clients.
Packaging & Shipping
FAQ
As one of the leading airflow grinder enterprises in China, we warmly welcome you to wholesale bulk discount airflow grinder in stock here from our factory. All customized products are with high quality and low price.
